    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor

    Ask Lasest Price
    Brand Name : WNK
    Model Number : WNK805
    Supply Ability : 2000 Piece/Pieces per Week
    Price : $45.00 - $65.00/Pieces
    Payment Terms : T/T, Western Union, MoneyGram, Paypal
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor

    4-20mA Smart Pressure Transmitter Hydraulic Oil Pressure Sensor For Liquid Gas Steam
    Specifications

    Silicon Flush Membrane Flush Diaphragm Pressure Sensor
    Applicable media
    Liquid, Gas, Steam
    Pressure measurment
    Gauge Pressure, Absolute pressure, Negative pressure, Sealing pressure
    Pressure range
    0-0.2 ...100kPa, 0-0.2 ...1000kpa, 60 MPa
    Output signals
    Typical output 4...20mA, 0.5...4.5VDC, For option: 1-5V, 0-5V, 0-10V DC
    Accuracy
    0.25%, 0.5%, 1.0%FS
    Stability
    ±0.25% FS/year
    Zero drift
    50% of full range span.
    Max overload
    200% of sensor range
    Display
    LED (Optional)
    Housing material
    304SS, 316L
    Mechanical connection
    M20×1.5; 1/2-18NPT, 1/4NPT, Customize
    Power supply
    Non-explosion: 10.5~45V DC
    EEX ia:10.5~30 V DC
    Ambient temperature
    -40~85℃
    Process temperature
    -40~85℃

    Features
    - Standard ranges from vacuum to 60Mpa
    - Accuracy up to ±0.25%
    - 4-20 mA 2-wire output signal, others available
    - Highly resistant to pressure spikes and vibration
    - Stainless steel case and wetted parts
    - Full range of process and electrical connections
    - Assemble to diaphragm seals for special applications
    - Suitable for gas, liquid, steam pressure measurement
    - Intelligent digital circuit with precise temperature characteristic compensation
    - Tantalum sensor contact for option for pressure measurement with corrosive media

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor
    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    Company Information

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor

    Exhibition

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    Certification

    WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor


    FAQ

    Q: Are you trading company or manufacturer ?

    A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

    Q: What's your quality control system?

    A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

    Q: What is the warranty of your products?

    A: 12 month from shipment date, for non-man-made damages.

    Q: Shipping and Delivery

    A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

    Large orders are recommended to ship by sea


    Quality WNK 304SS Intelligent Pressure Transmitter , OEM Hydraulic Oil Pressure Sensor for sale
